bizhub B5020i

Versatile, reliable and high-quality performance

  • 50 ppm in black & white
  • Paper formats: A6-A4
  • Easy operation and maintenance
  • Compact and solid design
  • Print documents directly from mobile devices
bizhub 5020i
bizhub 5020i
bizhub 5020i
bizhub 5020i
bizhub 5020i
bizhub 5020i

Functionalities

Functionalities

Copy

Functionality Copy
  • Card shot

    Prints copies of the front and back of the original on the same page, e.g. for passport and other ID

  • Copy features

    Duplex, 2in1 and 4in1 copying can be selected

  • Quality adjustments

    Improves the document quality by editing the density, brightness, etc.

Functionality Copy
Functionality Fax

Fax

Functionality Fax
  • Convenient fax distribution

    Fax destinations can be preconfigured in an addressbook

  • Fax forwarding

    Forwarding of incoming fax documents by email or to SMB folder instead of printing

  • IP-Fax

    Sending of fax messages via network between Konica Minolta MFPs; supports colour as well as black & white

  • PC-Fax

    Direct fax transmission from the PC

Green

Functionality Green
  • Eco mode

    Optimises the printer settings for lower energy, paper and toner consumption

  • Hibernate mode

    Manual or scheduled hibernate settings ensure low energy consumption with less than 1 watt during off hours

Functionality Green
Functionality Print

Print

Functionality Print
  • High print resolution

    For best output quality

  • Mobile Printing

    Possibility to directly print documents from a mobile device

  • MyTab

    Print driver customisation

  • Quiet mode

    Prevents noise disturbance due to reduced noise while printing

Scan

Functionality Scan
  • Scan-to-FTP

    Sends converted files to an FTP server

  • Scan-to-Me/Home

    Direct scan to own email address (Me) or SMB folder (Home) based on Active Directory information

  • Support of various scan formats

    Including TIFF, PDF, Compact PDF, JPEG, etc.

  • TWAIN scan

    for clever digitisation of documents

Functionality Scan
Functionality Security

Security

Functionality Security
  • Authentication

    User access by password, user name + password or ID card.

  • Network security

    Support for SSL/TLS, HTTPS, 802.1x and IPsec

  • Secure print

    Password entering is required at the printer before prints are released

Features

Features

bizhub B5020i

The bizhub B5020i impresses with high productivity and versatility. The amazing print speed combined with standard duplex printing and various optional functions make this a perfect solution for daily printing demands for any mid-sized to larger business.

  • Manage all your campaigns in one portal

    Colour LCD panel

    Intuitive operation thanks to 3.7-inch colour LCD display and additional 15-key touch pad that guide users smoothly through any job setting

  • Print feature icon

    Compact design

    Its small footprint and compact design make it perfectly suitable  even for the smallest office as well as desktop use

  • Sustainability feature icon

    Eco performance

    Eco-friendly performance thanks to the integrated Eco mode which lowers energy consumption, thus saving costs

bizhub 5020i
  • Technology feature icon

    Multifunctional allrounder

    Provides copy, print, scan and fax functionality in a single device enhancing the general workflow efficiency of daily routines

  • Customization feature icon

    User flexibility

    Standard colour scanning and the choice of various print functions like duplex print, secure print, n-up or electronic sorting mean enhanced flexibility for the user to process jobs

Print from anywhere, anytime:

mopria logo
Mobile Printing Web Icon

Specifications & Downloads

Specifications & Downloads
  • Panel size/resolution 4.85”
  • System memory (standard/max) 1,000 MB (standard/max)
  • Interface 10/100/1,000-Base-T Ethernet; USB 2.0; Wi-Fi 802.11 b/g/n
  • Network protocols TCP/IP (IPv4 / IPv6); LPD; IPP; SNMP; HTTP; HTTP(S)
  • Automatic Document Feeder Up to 80 originals; A6-A4; 64-90 g/m²; Dualscan ADF
  • Paper input capacity (standard/max) 570 sheets / 1,610 sheets (standard/max)
  • Paper tray input (standard) 1x 520 sheets; A6-A4; 60-120 g/m²
  • Paper tray input (optional) 1x 250 sheets; A5-A4; 60-120 g/m² (up to 2x)
    1x 520 sheets; A5-A4; 60-120 g/m² (up to 2x)
  • Manual bypass 50 sheets; A6-A4; custom sizes; 60-200 g/m²
  • Automatic duplexing A4; 60-105 g/m²
  • Output capacity (standard) 250
  • Copy/print volume (monthly) Rec. 10,000 pages; Max. 150,000 pages
  • Toner lifetime Black up to 20,000 pages
  • Imaging unit lifetime 50,000
  • Power consumption 220-240 V / 50/60 Hz; Less than 805 W
  • System dimension (WxDxH) 495 x 427 x 518 mm (without options)
  • System weight Approx. 18.9 kg (without options)
  • Print resolution 1,200 x 1,200 dpi
  • Page description language PCL 6 (XL3.0); PostScript 3; XPS
  • Operating systems Windows 7 (32/64); Windows 8.1 (32/64); Windows 10 (32/64);
    Windows Server 2008 (32/64); Windows Server 2008 R2;
    Windows Server 2012; Windows Server 2012 R2;
    Windows Server 2016; Windows Server 2019;
    Macintosh OS X 10.10 or later; Linux
  • Printer fonts 85 PCL Latin; 66 PostScript 3 Emulation Latin
  • Mobile printing Mopria (Android);
    Konica Minolta Print Service (Android);
    Konica Minolta Mobile Print (iOS/Android/Windows 10 Mobile);
    Google Cloud Print; WiFi Direct
  • Scan speed (mono/colour) Up to 50/20 ipm in simplex
    Up to 100/34 ipm in duplex
  • Scan resolution 1,200 x 1,200 dpi
  • Scan modes Scan-to-eMail (Scan-to-Me); Scan-to-FTP;
    Scan-to-USB; TWAIN scan; WIA scan
  • File formats JPEG; TIFF; PDF; XPS
    Optional: Searchable PDF
  • Scan destinations LDAP support
  • Imaging technology Laser
  • Toner technology Polymerized Toner
  • Copy/print speed A4 (mono) Up to 50 ppm
  • Autoduplex speed A4 (mono) Up to 24 ppm
  • 1st copy out time A4 (mono) 9.5 sec.
  • Warm-up time Approx. 27 sec.
  • Copy resolution 600 x 600 dpi
  • Gradation 256 gradations
  • Multicopy 1-999
  • Original format A6-A4
  • Magnification 25-400% in 1% steps; Auto-zooming
  • Fax standard Super G3
  • Fax transmission Analogue; i-Fax
  • Fax compression MH; MR; MMR; JBIG
  • Fax modem Up to 33.6 Kbps
  • Fax destinations 299 destinations + 20 groups
  • Security SSL2; SSL3 and TLS1.0/1.1/1.2 network communication; IPsec support; IEEE 802.1x support; Secure print; Kerberos
  • Accounting Active Directory support
    (user name + password + e-mail + smb folder)
    Optional: ID card authentication (ID card reader)
  • Software Net Care Device Manager; Web Connection; Driver Packaging Utility
1 If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed
2 Warm-up time may vary depending on the operating environment and usage

  • All specifications refer to A4-size paper of 80 g/m2 quality.
  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications and network protocols as well as network and system configurations.
  • The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size (5% coverage of A4). The actual life of each consumable will vary depending on use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • Konica Minolta does not warrant that any specifications mentioned will be error-free.
  • All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
